Prodigy to FMC-HPC Converter Module

Prodigy to FMC-HPC Converter Module

  • Converts two Prodigy I/O connectors to one FMC-HPC and one FMC-LPC connectors.

  • Provides two Push Button, one 2x7 Pin Header and three LEDs.

  • Occupies two Prodigy I/O connectors.



Prodigy to LM Converter Module

Prodigy to LM Converter Module

  • Converts one Prodigy I/O connector to one LM I/O connector.

  • Provides two 7x2 Pin Headers, twenty LEDs and four Push Buttons.

  • Occupies one Prodigy I/O connectors.

  • External power supply is not required.



Global Clocks Management Module

  • Provides three global clock sources.

  • Provides one 1to4 single-ended and Two 1to4 differential global clocks.

  • Provides one global reset source.

  • All global clocks and reset signals are output through SMB. connectors.

  • Single 5V Power Supply.



Global Clocks Management Module Type B (for LM)

Global Clocks Management Module Type B (for LM)

  • Provides 3 reset inputs through push button or MMCX, and output them to four SC connectors synchronized.

  • Provides 6 pairs of LVDS clock inputs through on-board programmable chip or MMCX and output them to four SC connectors synchronized.

  • Provides 3 pairs of LVDS clock outputs from each SC connector and use 4-to-1 mux (selectable by switches) to output them by MMCX connectors.

  • Provides one USB interface to program the clock chip.

  • Requires only a single 3.3V Power Supply.



Prodigy to Pin Header Module

Prodigy to Pin Header Module

  • Converts the Prodigy I/O connctor to four 2x21 Pin Headers and nine MMCX connectors.(3 single-ended and 3 LVDS pairs)

  • Occupies one Prodigy I/O connectors.

  • No external power supply required



Prodigy to FMC-LPC Converter Module

Prodigy to FMC-LPC Converter Module

  • Converts one Prodigy I/O connectors to one FMC-LPC connector.

  • Provides 2 pairs of LVDS clock input and outputs on MMCX.

  • Provides one switch, two 2x8 Pin Header and four LEDS.

  • Occupies one Prodigy I/O connectors.



Smart Power Switch Module Type B

Smart Power Switch Module Type B

  • Supports power ON/OFF the ATX power supply.

  • Provides 5V, 3.3V and 1.8V, source up to 3A.

  • Programmable power sequence for 5V, 3.3V and 1.8V

  • Supports remote power recycling for Logic Modules.

  • Provides one Ethernet Port for remote control.



MMCX to SMB Cable

  • Provides six LVCOMS input through MMCX connectors

  • Provides six LVDS output through SMB connectors



Global Clocks Management Module Type D V3.0 (for LS)

Global Clocks Management Module Type D V3.0 (for LS)

  • Provides 3 reset inputs through push button or MMCX, and output them to four SC connectors synchronized.

  • Provides 6 pairs of LVDS clock inputs through on-board programmable chip or MMCX, and output them to four SC connectors synchronized.

  • Provides 3 pairs of LVDS clock outputs from each of SC connectors and use 4-to-1 mux (selectable by switches) to output them by MMCX connectors.

  • Provides one Ethernet interface to program the clock chip.

  • Requires only a single 3.3V Power Supply.



Prodigy I/O Level Shifting Module

Prodigy I/O Level Shifting Module

  • Converts the signal level from 1.8V to 3.3V.

  • Occupies one Prodigy I/O connectors.

  • No need external power supply



Smart Power Switch Module




Global Clock Management Module Type B (for LS)

  • Provides 3 reset inputs through push button or MMCX, and output them to four SC connectors synchronized.

  • Provides 6 pairs of LVDS clock inputs through on-board. programmable chip or MMCX and output them to four SC connectors synchronized.

  • Provides 3 pairs of LVDS clock outputs from each SC connectors and use 4-to-1 mux (selectable by switches) to output them by MMCX connectors.

  • Provide one USB interface to program the clock chip.

  • Requires only a single 3.3V Power Supply.



Global Clocks Management Module Type D V3.0 (for LM)

  • Provides 3 reset inputs through push button or MMCX, and output them to four SC connectors synchronized.

  • Provides 6 pairs of LVDS clock inputs through on-board. programmable chip or MMCX, and output them to four SC connectors synchronized.

  • Provides 3 pairs of LVDS clock outputs from each of SC connectors and use 4-to-1 mux (selectable by switches) to output them by MMCX connectors.

  • Provides one Ethernet interface to program the clock chip.

  • Requires only a single 3.3V Power Supply.



Prodigy to HT3 Converter Module V2

Prodigy to HT3 Converter Module V2

  • Converts one Prodigy I/O connector to three HT3 connectors.

  • Provides three 7x2 Pin Headers.

  • Occupies one Prodigy I/O connectors.

  • No external power supply required.



Global Clocks Management Module Type E

Global Clocks Management Module Type E

  • Provides 3 reset inputs through push button or MCU, and outputs them to twelve SC connectors synchronized.

  • Provides 6 pairs of LVDS clock inputs through on-board programmable chip and outputs them to twelve SC connectors synchronized.

  • Provides one connector (JS13) that supports cascading.

  • Provides one Ethernet interface to program the clock chip.

  • Requires only a single 3.3V Power Supply.



Global Clocks Management Module V2.0 for LX

Global Clocks Management Module V2.0 for LX

  • Provides 4 reset inputs through push button or MCU, and output them to eight SC connectors synchronized.

  • Provides 12 pairs of LVDS clock inputs through on-board programmable chip and output them to eight SC connectors synchronized.

  • Provide one connector (JS13) that supports cascading.

  • Provides one Ethernet interface to program the clock chip.

  • Requires only a single 3.3V Power Supply.



Prodigy Interconnection Module Type A

  • Occupies two Prodigy I/O connectors.

  • No external power supply required



Prodigy I/O Testing Module

Prodigy I/O Testing Module



Prodigy DDR42PM Module

Prodigy DDR42PM Module



Power Switch Module

Power Switch Module



System Control Clock Module Type C

System Control Clock Module Type C

  • Provides 5 pairs of LVDS clock input on MMCX.

  • Provides 1 single-ended OSC socket.

  • Provides 3 reset inputs through push button or MMCX.

  • Provides 3 pairs of LVDS clock outputs on MMCX.

  • Provides power recycle control port for VU/KU Prodigy Logic Module.

  • External power supply is not required.

  • Occupies one SC connector.



Prodigy DDR32PM Module

Prodigy DDR32PM Module



System Clock Control Module Type D

System Clock Control Module Type D

  • Provides 5 pairs of LVDS clock input on MMCX

  • Provides 1 single-ended OSC socket

  • Provides 3 reset inputs through MMCX

  • Provides 3 pairs of LVDS clock outputs on MMCX

  • No need external power supply

  • Occupies one SC connector



Prodigy Interconnection Module Type H

  • Occupies two Prodigy I/O connectors.

  • External power supply is not required.



Prodigy Interconnection Module Type C

  • Connects 144 GPIO and 4 SerDes between two Prodigy I/O connectors.

  • Occupies two Prodigy I/O connectors and the spacing between two connectors is 75mm.

  • Provides a fixed 100MHz reference clock.

  • External power supply is not required.



Prodigy Interconnection Module Type D

  • Connects 144 GPIO and 4 SerDes between two Prodigy I/O connectors.

  • Occupies two Prodigy I/O connectors and the spacing between two connectors is 35mm.

  • Provides a fixed 100MHz reference clock.

  • External power supply is not required.



Prodigy Programmable Interconnection Module Type C

  • Connects 144 GPIO and 4 SerDes between two Prodigy I/O connectors.

  • Occupies two Prodigy I/O connectors and the spacing between two connectors is 75mm.

  • Provides a 10~810 programmable reference clock.

  • External power supply is not required.



Prodigy Programmable Interconnection Module Type D

  • Connects 144 GPIO and 4 SerDes between two Prodigy I/O connectors.

  • Occupies two Prodigy I/O connectors and the spacing between two connectors is 35mm.

  • Provides a 10~810 programmable reference clock.

  • External power supply is not required.



FMC I/O Testing Module V2.0




Prodigy Interconnection Module Type H for LX

  • Occupies two Prodigy I/O connectors.

  • External power supply is not required.



Prodigy Interconnection Module Type V for LX

  • Occupies two Prodigy I/O connectors.

  • External power supply is not required.



Prodigy Mezzanine Connector

Prodigy Mezzanine Connector



Prodigy Mezzanine Tall Connector

Prodigy Mezzanine Tall Connector



Prodigy Socket Connector

prodigy socket connector



DDR4 I/O Testing Module



1200mm Mini-SAS cable




300mm MMCX Cable




300mm MMCX to SMB Cable

300mm MMCX to SMB Cable



1000mm FireFly Cable




1000mm Prodigy Cable Type B



1000mm FireFly Cable Type B



200mm Mini-SAS cable



500mm FireFly Cable Type B



254mm Prodigy Cable Type B



635mm Prodigy Cable Type B



150mm Prodigy Cable Type B



600mm Mini-SAS cable
